Single-Unit Residential House
Single-Unit Residential House
| Medesigns
Medesigns
2895 Sq Ft | 4 Bed | 2 Bath | 1 Story | 1 Garage | dim
Width 50 | Depth 2
|
$ 699
First floor plan
Planas
Square footage
First floor 2895
Total heated 2895
Garage 710
Dimensions
Width 50' 595"
Depth 2' 24"
Height 15' 177"
Main roof pitch 0/2
Ceiling heights
Main level 11' 132"
Main features
Stories 1
Bedroom 4
Bathrooms 2
Garage spaces 1

The construction sector demands meticulous planning, especially when selecting roofing materials for building design. This project centers on the design of a modern, single-unit residential house, with the primary research problem focused on identifying the most suitable roofing materials to ensure optimal durability.

This modern house features numerous bedrooms and specialized rooms, including a gaming room, cinema room, and a luxurious SPA zone complete with a pool, sauna, and jacuzzi.

To address the project requirements, a comprehensive construction plan was developed, incorporating various planning and structural solutions. The project involved a comparative analysis of potential methods, the selection of building materials, the calculation of the covering slab structure, and the determination of the technology for covering installation. Additionally, criteria for construction organization were established, and the project's costs were justified.

After a multi-criteria evaluation of roofing options, the bituminous roofing material Technoelast Standard EKP was determined to be the best solution for this residential house.

Full specifications and features
Architectural Styles Modern, Classical, European
Structure type Single family home
Bedroom Features Split bedrooms, Guest suite, Main floor guestroom
Kitchen Features Country kitchen
Additional Room Features Den/Office/Study, Media room, Storage area, Great/Living room, Hobby/Rec room, Wine cellar
Garage Features Front entry, Side entry
Outdoor spaces Courtyard, Grill deck sundeck
Lot characteristics Suited for view lot, Suited for narrow lot, Suited for sloping lot
What's included?

Cover sheet

An artist's rendering of the exterior of the house shows you approximately how the house will look when it’s constructed and landscaped.


Floor plan(s)

Set of detailed plans for each floor, showing the room layouts, interior square footages, door/wall partitions and window sizes. Also included are suggested locations for your kitchen appliances, plumbing fixtures, electrical outlets, etc.


Exterior elevations

Front, rear, right and left side exterior elevations are shown including the exterior materials and measurements of your home.


Interior elevations

These drawings show a suggested layout design of cabinets, utility rooms, fireplaces, built-ins and other interior features depending on the complexity of your home.


Roof plan

Shows an overall bird ’s eye view of the roof layout, roof pitch, slopes and ridges of your roof design.


Foundation plan

This page gives you an overview of typical sections and details of the foundation. Every home has its own specific foundation requirements. You will need to verify and use the details pertinent to your home ’s foundation in addition to abiding by your local area building codes.


Cross-section details

These drawings are vertical cutaways views of your home detailing important relationships from one floor level to another, including changes in ceiling and roof heights.
