| First floor | 1560 |
| Total heated | 1560 |
| Width | 36' 432" |
| Depth | 3' 36" |
| Height | 11' 132" |
| Main roof pitch | 1/5 |
| Main level | 9' 108" |
| 2nd level | 9' 108" |
| Stories | 1 |
| Bedroom | 2 |
| Bathrooms | 2 |
| Garage spaces | 0 |
This elegant house design was inspired by the need to utilise every space required.The house looks small but it’s not small.Building it is easy due to its less consumption of materials.The need for affordable housing is the major inspiration to this design.It’s also a mixture of modern contemporary architecture and the traditional.Very ideal for both the country side and town areas.
| Architectural Styles | Contemporary, European |
| Structure type | Single family home |
| Bedroom Features | Split bedrooms, Guest suite |
| Kitchen Features | Country kitchen |
| Additional Room Features | |
| Garage Features | Detached garage |
| Outdoor spaces | Covered front porch |
| Lot characteristics |
Cover sheet
An artist's rendering of the exterior of the house shows you approximately how the house will look when it’s constructed and landscaped.
Floor plan(s)
Set of detailed plans for each floor, showing the room layouts, interior square footages, door/wall partitions and window sizes. Also included are suggested locations for your kitchen appliances, plumbing fixtures, electrical outlets, etc.
Exterior elevations
Front, rear, right and left side exterior elevations are shown including the exterior materials and measurements of your home.
Interior elevations
These drawings show a suggested layout design of cabinets, utility rooms, fireplaces, built-ins and other interior features depending on the complexity of your home.
Roof plan
Shows an overall bird ’s eye view of the roof layout, roof pitch, slopes and ridges of your roof design.
Foundation plan
This page gives you an overview of typical sections and details of the foundation. Every home has its own specific foundation requirements. You will need to verify and use the details pertinent to your home ’s foundation in addition to abiding by your local area building codes.
Cross-section details
These drawings are vertical cutaways views of your home detailing important relationships from one floor level to another, including changes in ceiling and roof heights.
